1. For A1 series Owner：
To connect AMS HT unit(s) to A1 series printer, an A1 series AMS Hub (SA013) is required.
A1 series printer can connect up to 4 AMS units(including AMS HT, AMS, AMS 2 Pro).
Note: AMS lite cannot be used in combination with other AMS units.
2. For X1/P1 series Owner：
To connect a single AMS HT unit to X1/P1 series printer, a Filament Buffer(SA003), a PTFE Tube Coupler(FAZ006), and a 4-pin Cable(CAB002-N) are required.
To connect multiple AMS HT units, an AMS Hub(SA002-N), a PTFE Tube Coupler(FAZ006), and a 4-pin Cable(CAB002-N) are required.
X1/P1 series printer can connect up to 4 AMS units(including AMS HT, AMS, AMS 2 Pro).
3. For P2S Owner：
To connect one or two AMS HT unit(s) to P2S, a P2S Filament Buffer (SA011) is required.
To connect more than two AMS HT units, a P2S Filament Buffer (SA011) and a 4-in-1 PTFE Adapter(s) (FAZ013-N) are required.
P2S printer can connect up to 4 AMS units(including AMS, AMS 2 Pro) and 4 AMS HT units.
4. For H2S Owner：
To connect more than one AMS HT units to H2S, a 4-in-1 PTFE Adapter(s) (FAZ013-N) are required.
To connect a single AMS HT unit, no extra accessory is required.
H2 series printer can connect up to 4 AMS units(including AMS, AMS 2 Pro) and 8 AMS HT units.
5. For H2D/H2C Owner：
To connect more than two AMS HT units to H2D/H2C, a 4-in-1 PTFE Adapter(s) (FAZ013-N) are required. For better performance, we recommend 4-in-1 PTFE Adapter II (SA014) for H2C.
To connect one or two AMS HT unit(s), no extra accessory is required.
H2 series printer can connect up to 4 AMS units (including AMS, AMS 2 Pro) and 8 AMS HT units.
6. For X2D Owner：
Connect 1 or 2 AMS HT unit(s)
To connect one or two AMS HT unit(s), no extra accessory is required.
X2D series printer can connect up to 4 AMS units (including AMS, AMS 2 Pro) and 8 AMS HT units.
Connect 3 or more AMS HT units
To connect 3 or more AMS 2 Pro units, a 4-in-1 PTFE Adapter(s) (FAZ013-N) is required.
X2D series printer can connect up to 4 AMS units (including AMS, AMS 2 Pro) and 8 AMS HT units.
7. For A2L Owner：
Connect 1 AMS HT unit
To connect one AMS HT unit, no extra accessory is required.
A2L series printer can connect up to 4 AMS units (including AMS, AMS 2 Pro and AMS HT) and 1 AMS lite.
Connect 2 or more AMS HT units
To connect more than one AMS HT units to A2L, 4-in-1 PTFE Adapter(s) (FAZ013-N) are required.
A2L series printer can connect up to 4 AMS units (including AMS, AMS 2 Pro and AMS HT) and 1 AMS lite.
Please check "What's in the box" section below. Some accessories are included, you may purchase extra as needed.
